Hover to zoom · click to expandSystem Sensor
System Sensor 2351E Conventional Photoelectric Smoke Detector
₹950
In stock
🚚 Delivery in 3–7 days
1
Conventional Smoke Detector: photoelectric, 8-30 V DC, EN 54-7
Specifications
| Model | 2351E |
| Sensor | Photoelectric |
| Operating Voltage | 8 to 30 V DC (12/24 V DC nominal) |
| Standby Current | 50 µA at 24 V DC |
| Alarm Current | 80 mA at 24 V DC (panel limited) |
| Operating Temperature | -30 to +70 °C |
| Humidity | 5 to 95% RH, non-condensing |
| Dimensions | 102 mm diameter x 38 mm (plus 9 mm with B401 base) |
| Weight | 105 g (plus 60 g for B401 base) |
| Material | Bayblend FR110 |
| Standard | EN 54-7 |
| Pack Size | 1 unit |
₹950
1
Description
Low-profile photoelectric smoke detector for conventional fire alarm panels, with a bi-colour status LED. Works on 8 to 30 V DC (12/24 V nominal) and fits the Series 100 / B401 range of bases. 102 mm diameter, 38 mm high (plus 9 mm with B401 base), 105 g. Tested to EN 54-7. Sold as 1 unit.
