Agni Orion 4 Zone Conventional Fire Alarm Panel
₹7,200
In stock
🚚 Delivery in 3–7 days
1
Conventional Fire Alarm Panel: 4 zones, 220 V AC, IS 2189
Specifications
| Model | Orion 4Z |
| Zones | 4 |
| Supply | 220 V AC mains input, 24 V DC output; built-in charger for SMF battery |
| End-of-Line Resistor | 4.7 kΩ, one per zone |
| Outputs | Common hooter output with individual zone outputs; NO/NC relay for fire and for fault |
| Display | 2 x 16 character backlit LCD plus zone LEDs (healthy, isolate, short, open, fire) |
| Controls | Reset, lamp test, silence, isolate |
| Enclosure | 1.8 mm CRCA sheet, powder coated |
| Dimensions | 275 x 325 x 95 mm |
| Weight | 4.475 kg (approx.) |
| Standard | IS 2189:1999 |
| Operating Conditions | 0 to 50 °C |
| Pack Size | 1 unit |
₹7,200
1
Description
Conventional fire alarm control panel with 4 detection zones. Runs on 220 V AC with a 24 V DC output and a built-in charger for a sealed maintenance-free standby battery. Backlit 2 x 16 LCD and zone LEDs show healthy, open, short, isolate and fire states; NO/NC relay contacts for fire and fault. Powder-coated 1.8 mm CRCA enclosure. Complies with IS 2189:1999. Sold as 1 unit.
